TPU2000/2000R Modbus/Modbus Plus Automation Guide
331
5/1 Coefficient B |
5/2 Coefficient B |
5/3 Coefficient B (low byte)
6/1 Coefficient C (high byte)
6/2 Coefficient C |
6/3 Coefficient C |
7/1 Coefficient C (low byte)
7/2 Coefficient P (high byte)
7/3 Coefficient P |
8/1 Coefficient P |
8/2 Coefficient P (low byte)
8/3 Spare
9/1 Spare
9/2 Checksum (high byte)
9/3 Checksum (low byte)
13.2 Receive First Overcurrent Curve Data Set ( 3 13 2 )
Data Byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
2/2 Spare
2/3 Command + Subcommand = 0xd2
3/1 Programmable curve number
User Programmable Curve number: 1=User 1; 2=User 2; 3=User 3
3/2 Segment 0: Endrange (high byte)
3/3 Segment 0: Endrange (low byte)
4/1 Segment 0: Alpha (high byte)
4/2 Segment 0: Alpha |
4/3 Segment 0: Alpha |
5/1 Segment 0: Alpha (low byte)
5/2 Segment 0: Beta (high byte)
5/3 Segment 0: Beta |
6/1 Segment 0: Beta |
6/2 Segment 0: Beta (low byte)
6/3-9/3 Segment 1 (same as segment 0)
10/1-14/1 Segment 2 (same as segment 0)
14/2-18/2 Segment 3 (same as segment 0)
18/3-22/3 Segment 4 (same as segment 0)
23/1-27/1 Segment 5 (same as segment 0)
27/2-31/2 Segment 6 (same as segment 0)
31/3-35/3 Segment 7 (same as segment 0)
36/1 Spare
36/2 Checksum (high byte)
36/3 Checksum (low byte)
13.3 Receive Next Overcurrent Curve Data Set ( 3 13 3 )
Same format as ( 3 13 2 ).
13.4 Receive Overcurrent Curve Pointer Table ( 3 13 4 )
Data Byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
