TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
342
Data Byte
Definition
1/1 Most significant high byte of password
1/2 Most significant low byte of password
1/3 Least significant high byte of password
2/1 Least significant low byte of password
2/2 Spare
2/3 Command + Subcommand = 0xe0
3/1 Trigger source (byte 1)
Bit 0: 87T
Bit 1: 87H
Bit 2: 51P-1
Bit 3: 51N-1
Bit 4: 50P-1
Bit 5: 50N-1
Bit 6: 150P-1
Bit 7: 150N-1
3/2 Trigger source (byte 2)
Bit 0: 46-1
Bit 1: 51P-2
Bit 2: 51G-2
Bit 3: 50P-2
Bit 4: 50G-2
Bit 5: 150P-2
Bit 6: 150G-2
Bit 7: 46-2
3/3 Trigger source : (byte 3)
Bit 0: Through Fault
Bit 1: Harmonic Restraint
Bit 2: External (WCI)
4/1 Trigger source:reserved (byte 4)
4/2 Trigger position quarter cycle:
0 to 255 (for 64 qtr cycle record)
0 to 128 (for 32 qtr cycle record)
0 to 64 (for 16 qtr cycle record)
0 to 32 (for 8 qtr cycle record)
4/3 Mode/Record Size
bit 0, 1: 00 = 8 rec of 8 qtr cycle record
01 = 4 rec of 16 qtr cycle record
10 = 2 rec of 32 qtr cycle record
11 = 1 rec of 64 qtr cycle record
bit 6: Single Shot Mode (0=Off, 1=On)
bit 7: Append Record Mode (0=Off, 1=On)
5/1 Spare
5/2 Checksum high byte
5/3 Checksum low byte
14.1 Report Waveform Capture Settings ( 3 14 1 )
Data Byte
Definition
1/1 Relay Status (see command 3 4 1, msg 1/1)
1/2 Command + Subcommand = 0xe1
1/3 Total Number of Messages = 9
2/1 - 6/3 Unit ID Name (15 characters)
7/1 Trigger source (byte 1)
Bit 0: 87T
Bit 1: 87H
Bit 2: 51P-1
Bit 3: 51N-1
