UNISEC INSTALLATION MANUAL
32
Panel for coupling unit with WBC – WBS to unit with 12-17.5 kV, 630 A
switch-disconnector
Panel for coupling unit with WBC – WBS to unit with 12-17.5 kV, 800 A
switch-disconnector
12-17.5 kV, 630 A middle unit 12-17.5 kV, 630 A end unit
12-17.5 kV, 800 A middle unit 12-17.5 kV, 800 A end unit
—

