40
NOTE
In the case of a circuit-breaker, fit the floor plates
as far apart from each other as possible so that the
cables can be fitted directly to as vertical a
position as possible
NOTE
During mounting of the power cables, check that
earth connection passes through the toroid (see
figure below)
NOTE
Check that P1 contacts of the toroid is mounted on
supply side of the plant
4. Cable clamps
3
NOTE
With SBC-W, the circuit-breaker can be removed as
indicated in the Operation manual
Figure 94. Connecting the cables
Figure 95. Installation of the floor plates,
cable guide splines, cable clamps and fairleads
Figure 96.
Figure 97. Installing the loose parts of the cable clamps
—
