ABB UniSec User Manual

14
4.3.3 Medium voltage cable locations and lengths
The medium voltage cable lengths (distance of the cable con-
nection point from the floor) depend on the units and acces-
sories used. The following figures and table show the cable
lengths and locations for the different units.
Table 4. Medium voltage cable lengths and locations
Figure 34. Medium voltage cable lengths
RLC unit
Details
190 mm width 375 mm width 500 mm width 600 mm width 750 mm width
A (mm) B (mm) A (mm) B (mm) A (mm) B (mm) A (mm) B (mm) A (mm) B (mm)
SDC Basic
––915210915275––––
SDC With CT
––––525275––525275
SDM Basic
–––––––– 525
(1)
275
(1)
SFC 292 mm fuse
––600200600230––––
SFC 442 mm fuse
––450200450230––––
SBC Basic
––––––––500310
WBC Basic or with CT
––––––600 150
(2)
600 165
DRC Basic
––500165670255––––
DRC With CT
––––530275––––
SBR Basic
––––––––400390
RLC/RRC Basic
1495 310 ––––––––
(1)
With optional cable terminal
(2)
Distance between panel side wall and fi rst cable connection
