COMM, WLAN LEDs behaviour
The following table shows all the possible status of “COMM” and “WLAN”
LEDs on the LED panel
06
according to the operating status of the wire-
less board.
LED Description
COMM
(MULTICOLOR)
Operation status of wireless communication line:
Blink Red: Communication error (no communication available)
Green: Communication OK
WLAN
(MULTICOLOR)
Communication type and quality of the wireless communication signal (for
“Station Mode”):
Blink Blue: Wireless board is working in Access Point mode (AP Mode)
OFF: No signal
Blink Red: Low signal strenght
Blink Yellow: Medium signal strenght
Blink Green: High signal strenght
