ABB V-Contact VSC Series User Manual

14
5.3. Normal conditions
Follow the recommendations in the IEC 62271-1 and 62271-106
Standards. In more detail:
Ambient temperature
Maximum + 40 °C
Average maximum over 24 hours + 35 °C
Minimum(accordingtoclass–5),
apparatus for indoor installation
– 5 °C
Humidity
Theaveragevalueoftherelativehumidity,measuredfora
periodlongerthan24hours,mustnotexceed95%.
Theaveragevalueofthewatervapourpressure,measuredfor
aperiodlongerthan24hours,mustnotexceed2.2kPa.
Theaveragevalueoftherelativehumidity,measuredfora
periodlongerthan1month,mustnotexceed90%.
Theaveragevalueofthewatervapourpressure,measuredfor
aperiodlongerthan1month,mustnotexceed1.8kPa
Altitude
< 1000 m above sea level.
5.4. Special conditions
Installations above 1000 m a.s.l.
Possible within the limits allowed by reduction of the dielectric
resistance of air.
For altitudes over 2000 m ask ABB.
Climate - Increase in temperature
In order to avoid the risk of corrosion or other damage in
areas with high humidity and/or rapid large fluctuations
intemperature,takeappropriatemeasures(forexample,
using suitable electric heaters) to prevent any condensation
phenomena.
For special installation requirements or other operating
conditions,pleasecontactABB.
5. Installation
5.1. General
Correct installation is of primary importance. The
manufacturer’sinstructionsmustbecarefullystudiedand
followed. It is good practice to use gloves for handling the
pieces during installation.
The areas involved in the passage of power
conductors or conductors of auxiliary
circuits must be protected against access of
any animals which might cause damage or
disservices.
Thecontactorenclosuremustbeinstalledinaclean,dry
and heated place with good ventilation. It must be easily
accessibleforcleaningandinspection,andmustbelevelled,
placed on the supporting foundations and securely fixed into
position.
Whenthecontactorisconnectedtoacapacitiveload,make
sure that there is a heating element to keep the humidity
down and of suitable size for the compartment where the
contactor is installed. The contactor must always be installed
associatedwithasuitableprotectiondevice(e.g.:fuses).
The fixed version of the V-Contact VSC
contactors must be installed by the customer
so as to guarantee a minimum degree of
protection of IP2X.
5.2. Installation and operating
conditions
The following Standards must be taken into particular
consideration during installation and service:
– IEC62271-1/DIN VDE 0101
– VDE 0105: Operation of electrical plants
– DIN VDE 0141: Earthing systems for electrical installations
with rated voltage higher than 1 kV
– All the accident prevention regulations in force in the relative
countries.
