VersaRupter MV Indoor Switch | Installation and Operation Manual 24
Mounting the NM Motor Operator on A-Mechanism
4. Slide the NM motor onto the splined shaft of the A-
mechanism and secure it with bolts, washer, lock
washers, and nuts as shown in figure 45.
Figure 45
Figure 46
