WaterMaster
Electromagnetic flowmeter 3 Mechanical Installation
6 IM/WM–EN Rev. M
Fig. 3.4 Localized Heat
Fig. 3.5 Siting
Fig. 3.6 Straight Pipe Requirements
Fig. 3.7 Fluid Level
Allow room to read display
Min.
Min.
>5 x Pipe Dia.0 x Pipe Dia.
Flow Direction
