ABB-Welcome
System controller
Article number: 83300-500
Functions
» Supplies and controls the entire door communication system
» The ABB-Welcome outdoor stations, the ABB-Welcome
indoor stations and the electric door opener as well as the
hall light are connected to the system controller
» The switching duration of door opener and light can be
adjusted
Technical data
Operating temperature: -5°C–+45°C
Protection: IP 20
Single-wire clamps: 2 x 0.6 mm
2
–2 x 1 mm
2
Fine-wire clamps: 2 x 0.6 mm–2 x 0.75 mm
2
Bus voltage: 28 V– ±2V; 1.5 A
Mains voltage: 100–240 V; 50–60 Hz; 0.9 A
Cross section of connection for 230V: 1.5mm² – 2.5mm²
Power supply for door opener: ~12V; 1.6A
Floating output for door opener: 30VAC/DC; 3A
Floating output for light: 230V~; 3AX
Size: 12 MW
QR-Code service
www.busch-jaeger-catalogue.com/
8300-0-0218,artikel.html
ABB-Welcome
Indoor station with display
Article number: 83200 U-500,
Article number for cover plates: 83260-xxx-500, 2gang frame
Functions
» Large illuminated, monochrome display 3.8 cm (1.5")
» Feedback signals in the display make operation easier for
the user since he gets constant feedback about the setting
that is currently being made
» Automatic activation of the screen at an incoming door call
» Hands-free function with suppression of noise and echo
interference for audible communication
» The basic functions of communication, opening of doors,
switching of lights and mute function are located directly on
the rocker switch and are quick and easy to adjust
» Differentiating between door call and floor ringing
» Five ring tones can be selected
» Monitoring barrier
» Five-stage adjustable volume
» Automatic door opening function, opens the front door
when the doorbell button is pressed
» Power supply and data transmission via 2-wire bus; ad-
ditional wiring with indoor station for auxiliary power is not
required
Technical data
Operating temperature: -5°C–+40°C
Protection: IP 30
Single-wire clamps: 2 x 0.6 mm
2
–2 x 1 mm
2
Fine-wire clamps: 2 x 0.6 mm
2
–2 x 0.75 mm
2
Bus voltage: 28 V – ±2 V
