ABB Power Distribution 19
Figure 3/14: Control cabinet
37.3 Perforated sheet
37.4 Terminal-strip holder
Figure 3/15: Control cabinet, terminal-strip holder swung upwards
10.4 Auxiliary switch for control wiring plug
37.4 Terminal-strip holder
37.5 Screw for terminal-strip holder
37.5
10.4
37.4
37.4 37.3
Figure 3/16: Mechanical plug interlock
10.1 Socket
10.2 Plug
32 Interlock lever
Figure 3/17: Lock for earthing switch manual mechanism.
14.9 Padlock
14.9
10.2
10.1
32
