Abbott Eterna 32400 - Generator Operating Parameters; Compatibility with Non-Abbott Leads

The generator has the following operang parameters.
Table 4. Operang parameters for the generator
Parameter Tonic Range Tonic Steps Burst Range* Burst Steps*
Pulse width 20–1000 µs 10 µs
(20–500 µs range)
50 µs
(500–1000
µ
s range)
50–1000 µs 50 µs
Frequency 2–200 Hz 2 Hz — —
200–500 Hz 10 Hz — —
500–1200 Hz 20 Hz — —
Burst frequency — — 10–60 Hz 10 Hz
Intra-burst rate — — 250–500 Hz 10 Hz
500–1000 Hz 20 Hz
Amplitude 0–25.5 mA 0.1–1.0 mA
0–12.75 mA 0.05–0.50 mA
0–12.75 mA 0.05–0.50 mA
NOTE: Columns with * represent operang parameters for
BurstDR
™ smulaon programs on generators
capable of
BurstDR
smulaon mode.
NOTE: For each tonic program, you have the opon to select the amplitude range. For informaon on
seng the amplitude range, see the clinician's programming manual for this system.
NOTE: The number of sm sets in use for a tonic program governs the maximum frequency (1200/
number of sm sets).
NOTE: The maximum current depends on the impedance, frequency, and pulse width sengs.
Adapters and Extensions for Compability with Non-Abbo Leads
The
Eterna
™ implantable pulse generator is compable with select
Medtronic
leads and extensions.
However, a compable adapter or extension must be used to connect the
Eterna™ implantable pulse
generator to Medtronic
leads. Compable adapter and extension models are listed in the following table.
Refer to the clinician manuals of the
A127
™ extension and the 8‑channel adapter for the list of compable
Medtronic leads and extensions.
Table 5. Compable Abbo Adapters
Device Model
A127™ Extension
2341, 2342, 2343, 2346
8‑Channel Adapter 2311, 2316
WARNING: Always use a compable adapter to connect the Eterna™ implantable pulse generator to
compable Medtronic leads and extensions. Do not insert a Medtronic lead or extension directly into
the Eterna generator header as this may damage the header.
12
