ABELL A-82 UHF Service Manual
第 3 页 共 41 页
66 6.8UF Type R ±20% 6.3V 1 C245
Inductor
67
BLM18AG601SN1D
0603 Magnetic Beads
600R
5 L1 L3 L9 L400 L401
68 MLF1608DR22K 0603
Lows Multi-layer
inductor
2 L5 L6
69
LQH32MN1ROM23
1210 Winder、Ferrite 1 L207
Diode
70 DAN222 SOT-416 DIODE 1 D401
71 1SS372 SOT-323 DIODE 2 D4 D400
72 LED-02-
0603 QRC
D0603 Red light 1 LED1
73 LED-02-
0603 QGC
D0603 Green light 1 LED2
74 MA2S11100L SOD-523 DIODE 2 D2 D3
Triode
75 2SC4617 SOT-416 TRANSISTOR 3 Q16 Q400 Q401
76 2SC4919 SOT-523 TRANSISTOR 1 Q403
77 2SK1824 SOT-416 FET 2 Q203 Q402
78 DTA114YE SOT-416 TRANSISTOR 1 Q15
79 DTA143ZE SOT-416 TRANSISTOR 1 Q405
80 DTA144EE SOT-416 TRANSISTOR 1 Q206
81 DTC114EE SOT-416 TRANSISTOR 5 Q2 Q3 Q5 Q6 Q202
82 DTC114TE SOT-416 TRANSISTOR 1 Q215
83 FMMT717 SOT-23 TRANSISTOR 1 Q4
IC
84 AT24C64 SOP8 EEPROM 1 IC3
85 NJM2904V SSOP8 ACTICE FIL TER 1 IC201
86 NJM2100V SSOP8 IC（AUDIO AMP） 1 IC400
87 PST9140NR SOT-25A RESET 1 IC6
88 R5F212A8SNFP QFP64 Programmed CPU 1 IC1
89 RN5VL45C SOT-25A VOL TAG DETECT 1 IC7
90 XC6201P502PR SOT-89-3L IC（5V
steady voltage
1 IC4
91 TDA2822 SOP8 AUDIO AMP 1 IC2
92 WTV040-20SS SSOP20
WTV070825-
1D44K
Record
1 IC5
93 XC6219B332MR QFP5 3.3V
steady voltage
1 IC8
Fuse
94 3A-32V 1206 R429003-3A-32V 1 FU2
Crystal
95 9.8304MHz
8.0×4.5×1.8mm
NX8045GB 1 X1
