ABELL A-82 UHF Service Manual
第 4 页 共 41 页
Version: 01 A82(D04) B Side BOM
No. Specification Packing Description Qty Part No.
Chip Resistor
1 0R 0402 ±5% 6 R24 R111 R304 R308 R453 R456
2 0R 0603 ±5% 1 R201
3 0R 0805 ±5% 1 R203
4 10R 0402 ±5% 3 R103 R129 R216
5 10R 0603 ±5% 1 R312
6 22R 0402 ±5% 4 R120 R218 R222 R336
7 47R 0402 ±5% 2 R200 R202
8 100R 0402 ±5% 6 R76 R101 R114 R117 R133 R331
9 100R 0603 ±5% 1 R123
10 150R 0402 ±5% 1 R314
11 180R 0402 ±5% 2 R121 R130
12 220R 0402 ±5% 1 R323
13 270R 0402 ±5% 3 R125 R204 R205
14 330R 0402 ±5% 2 R217 R221
15 470R 0402 ±5% 2 R300 R329
16 560R 0402 ±5% 2 R106 R140
17 680R 0402 ±5% 3 R220 R232 R233
18 820R 0402 ±5% 1 R457
19 1K 0402 ±5% 10
CP5 R25 R39 R48 R77 R107 R127 R426
R460 R462
20 1.2K 0402 ±5% 1 R128
21 1.5K 0402 ±5% 1 R219
22 1.8K 0402 ±5% 2 R338 R339
23 2.2K 0402 ±5% 3 R108 R313 R455
24 2.7K 0402 ±5% 3 R109 R461 R463
25 2.7K 0603 ±5% 1 L313
26 3.3K 0402 ±5% 9
R105 R124 R224 R225 R332 R334 R436
R458 R459
27 3.9K 0402 ±5% 2 R35 R321
28 4.7K 0402 ±5% 5 R57 R58 R137 R231 R301
29 5.6K 0402 ±5% 5 R104 R434 R440 R450 R452
30 6.8K 0402 ±5% 1 C148
31 10K 0402 ±5% 6 R38 R110 R119 R441 R464 R465
32 12K 0402 ±5% 1 R433
33 15K 0402 ±5% 3 R112 R466 R467
34 18K 0402 ±5% 1 R442
35 22K 0402 ±5% 2 R207 R427
