ABELL A-82 UHF Service Manual
第 9 页 共 41 页
163 NJM2904V SSOP8 ACTICE FIL TER 1 IC301
164 TA31136FN TSOP16 IF SYSTEM 1 IC300
165 MB15E03SLPFV1 SSOP16 PLL 1 IC100
Ceramic filter
166 LTWC450F
11.6×7.5×3.3mm
IF filter (With direction
)
1 CF300
Crystal
167 12.8MHz 3.2×5mm NSA0298A 1 X100
168 MCF 38.85MHz SMD
crystal filter﹙With
direction﹚
1 XF301
Feather-touch
function button
169 TSHW-2VSL 7×2.5mm 2 S1 S2
170
PCB
(A82 UHF V01)
PSW
V1.0 V01
09.2.8
UHF
1
Version:01 A82(D04) Post-Weldment BOM
No.
Specification Packing Description Qty
Part
No.
No.
1
Frequency
discriminator
JTBM450C24 1 CF301
2 Mic
FOM9745P-G421 or
CZ034CP421-X15(GP)
Φ9.7×4.5mm
1 M1
3
feather-
touch function
button
180 Gram 3×6mm 1 S3
4 Mic Jack ST-212 1 J1
5 Earphone Jack PJ-204A 1 J2
6 Encoder EC10SP16-103AO ENCODE 1 CN1
7 potentiometer
Switch
R08710NS-FE15C7.0-A103-
00A
1 CN10
8
Speaker Connection
One pcs of red wire and one pcs
of black wire，
7pin copper wire
0.12±0.01mm
Φ1.0×80 mm
PVC
2
9 Speaker 16R/1W φ40 ND040GM8X16 1
10 bridle wire φ1.0×21×5mm 2
