ABELL A-82 UHF Service Manual
第 10 页 共 41 页
Version： 01 A82(D04) Assembly Parts BOM
Material No. Material Specification
Quantity
Remark
F04A82-003 half product 1
Assembly：
：：
：
Plastic parts
P01A82-026 Housing 1 PC+ABS
P08A82-008 Volume Knob 1 PC+ABS
P07A82-008 Channel knob 1 PC+ABS
P17A82-003 Speaker Cover 1 PC+ABS
P04A82-008 LED 1 PC
P02A82-005 Anode Bracket With 4PIN thimble 1 PA68
P12A82-004 Back Button 1 PC+ABS
P05A82-007 Back Shoulder 1 PC+ABS
P26A82-002
Lanyard separation
blade
1 PC+ABS
P30A82-002 Bolt Φ2.8×2mm 2 PC+ABS
P30A82-003 Bolt Φ2.8×3mm 5 PC+ABS
P06A82-008
Earphone and
microphone cover
1 TPU/80 Degree
P21A82-003
Earphone and
microphone inside cover
1 TPU/80 Degree
P06A82-006 non-slipping cover(left
)
1 TPU/80 Degree
P06A82-007 non-
slipping cover(right)
1 TPU/80 Degree
Single side Glue:
S02A82-020 PVC Back glue 20.5×4.5mm 1
S07307-003 Speaker dustproof φ38×48 1 N-250#（imported from U.S）
S02307-001
Speaker sponge sheet
φ16×1（Unit：mm） 1
S02307-003 Crystal sponge sheet 7×4×1(mm) 1
S02A81-016 Crystal sponge sheet 11.5×6.5×4.0mm 1
S06307-007 Heat radiate silica gel 6.5×7.5×1.0mm 1 With 2SK3476
S07A82-007 Mic dustproof φ11mm 1 Back with 3M glue
S02A82-022
non-
slipping cover(left)
double faced adhesive
tape
1 TPU/80 Degree
S02A82-023
non-
slipping cover(right)
double faced adhesive
tape
1 TPU/80 Degree
Rubber Parts:
L01A82-011 PTT rubber sheet 1 RUBBER'50
.
L02A82-021
Anode and cathode
rubber sheet
1 RUBBER'30
.
L03A82-008
Rubber waterproof sheet
1 RUBBER'30
.
