ABELL A-82 UHF Service Manual
第 11 页 共 41 页
L09A82-002 Mic rubber sheet 1 RUBBER'30
.
L08A82-007 heat shrinkage bush φ1.0×14mm 1 Used for heat shrinkage bush anode
L03A81-006 Knob waterproof ring 2 RUBBER'30
.
L03A81-005
Antenna waterproof ring
1 RUBBER'30
.
Metal Parts:
M21A82-002 Speaker steel net 0.15 Stainless steel 1
M07A82-007 Belt clip base 1
M17A82-015 Aluminum Case 1 ADC12
MPM025-134 Screw Φ2.5×4PM 2 Gold-plate used for main label
MPM025-104 Screw Φ2.5×7PM 2
Nickelage used for housing and
aluminum chassis
MKM025-114 Screw Φ2.5×7KM 3 Nickelage used for belt socket
MPB020-064 Screw Φ2.0×4.5PB 2 Nickelage used for Anode Bracket
M18A82-016 Belt Spring ф1.0 1
M02A81-006 Belt Shaft Φ1.9×23.9(Unit:mm) 1
M19090-007 Round cupreous nut Φ9.0×2.0×M7 1 aurichalceous together with encoder
A02307-002 Antenna socket SMA-JFD-13(new) 1
M23A82-002 Knob 0.2mm 2 Include volumn and channel knobs
MKM025-013 Screw Φ2.5×5KMH 2 Antenna socket screw
MPB020-033 Screw Φ2.0×3.5PBH 12 Tapping screw
M19040-002 nut Φ4.0×3.5×M2.5 2 Aurichalceous Used to fix aluminum hull
M19035-004 nut Φ3.5×3.0×M2.5 2 Aurichalceous Used to fix the logo
M19095-002 Round cupreous nut M08701-Φ9.0×2.0 1 Aurichalceous match with potentiometer
M19013-001 Antenna socket nut Φ13.5×2.5×M9 1 Aurichalceous
match with antenna socket
M18308-006 Belt clip spring clip 1
Label Parts:
T15A82-025 “ABELL” 0.8t Stainless steel 1
T15A82-028 “A-82” 0.5t Stainless steel 1
T11308-000 Radio PN code 1
T12A82-007
Frequency range label
29×39mm 1
Accessories:
RTV white silica gel
(AST-803#)
1.2mL
