25
Toplink - Be sure to keep the threaded parts of toplinks greased so they don’t seize over time.
Finish Rake - Occasionally over the life the tool, bent finger(s) on the finish rake may appear. If this occurs, place a pipe over the
bent finger and use the pipe as leverage to straighten the finger back out.
Grooming Rods - If one of the grooming rods appears to be bent, use a vice and hammer to bend it back straight.
Finish – To prevent rust from developing on a surface due to scratches on the tool, use a rust stopping primer and semi-gloss
black paint to refinish the damaged area.
Wheels and Hubs - The bearings in the hubs on the TR3-E should be greased every 3 months. They should also be greased before
any long period of storage. (see Figure 13)
Maintenance
Location of Grease
Fitting on Wheel
Hub Assembly
Figure 13.
