Assemble out rake sections as shown with
bent ends angles upward.
Initial Setup Instructions
(Equine Edition)
Initial Setup Instructions
(Trevor Brazile Edition)
1. Use the same initial Setup Instructions as the Property Edition above.
1. For Units that are shipped with outer Rake sections removed (as shown in Figure 4), remove bolts and nuts (3/4” Hex) from
Rake support bracket. Set End Rake sections on Rake support bracket and re-insert bolts and nuts and tighten (see Figure 5). Bent
ends of Rake Sections are to be angled upwards (see Figure 6).
Figure 4.
Figure 5.
Figure 6.
Setup (cont'd)
