ABI Attachments TR3-E Series - ASM: Rake: 6 FT;7 FT;8 FT

Call Toll Free: 877-788-7253Email: support@abiattachments.com
31
ASM: Rake: 6FT/7FT/8FT
ITEM PART # DESCRIPTION
1 10-20050 1/2-13 TOP LKGRC
2 10-20179 HX HD BOLT: 3/4-10 4.5": ZINC GR5
3 10-20194 FLT WSHR: 1/2 SAE: CL ZINC
4 10-20197 FLT WSHR: 3/4 SAE GR5: ZINC
5 10-20344 NYLOCK NUT: 3/4-10 : ZINC GR5
6 10-20359 HX HD BOLT: 1/2-13 1.75": ZINC GR5
7 10-31074 24" FINISH RAKE EXTENSION SILVER, 1/2" RH
8 10-31075 24" FINISH RAKE EXTENSION SILVER, 1/2" LH
9 10-40358 WLDMT: RAKE 6': TR3 E V2
9 10-40359 WLDMT: RAKE 7': TR3 E V2
9 10-40360 WLDMT: RAKE 8': TR3 E V2
10 10-50001 12" COMB: .5" THICK
1
8
9
6
3
10
2
4
5
