34
ITEM PART # DESCRIPTION
1 10-20145 5/8 SAE F/W ZNC
2 10-20194 FLT WSHR:1/2 SAE: CL ZINC
3 10-20201 NYLOCK NUT:1/2-13:ZINC GR 5
4 10-20209 NYLOCK NUT:5/8-11:ZINC CL
5 10-20221 BENT PIN:1/2"X3.5":ZINC
6 10-20232 LYNCH PIN:1/4"X1.25":ZINC
7 10-20291 HX HD BOLT:5/8-11 4.0":ZINC GR5
8 10-20293 CARR BOLT:5/8-13 3.00":ZINC GR5
9 10-20320 HX HD BOLT:1/2-13 4.50":ZINC GR5
10 10-31055 BRKT: LH PROFILE BLADE ANGLE: TR3 E
11 10-31056 BRKT: RH PROFILE BLADE ANGLE: TR3 E
12 10-40268 WLDMT: 6' PROFILE BLADE PIVOT: TR3 E
12 10-40266 WLDMT: 7' PROFILE BLADE PIVOT: TR3 E
12 10-40271 WLDMT: 8' PROFILE BLADE PIVOT: TR3 E
13 10-40269 WLDMT: 6' PROFILE BLADE:TR3
13 10-40267 WLDMT: 7' PROFILE BLADE:TR3
13 10-40272 WLDMT: 8' PROFILE BLADE:TR3
ASM: Profile Blade: 6FT/7FT/8FT (cont'd)
