Abicor Binzel ABICOOLER 2000 advanced - Before Initial Startup and Commissioning

2000 advanced/2000 6 Startup and Commissioning
6.2 Connecting the coolant recirculator
6.2.1 Fuse protection for the coolant recirculator
NOTICE
The 2000 coolant recirculatior is protected by a 3A fuse
The 2000 advanced is protected by a resettable fuse (Figure 9).
Resettable fuse
Figure 9 Resettable fuse
If the cooling unit does not work, check:
• the power supply – switch on if necessary
• the fuse (1) – replace if necessary (2000).
6.3 Before initial startup and commissioning
Figure 10 Front
EN-13
1 Coolant inlet 2 Coolant filler pipe 3 Cap 4 Coolant filter
5 Coolant return pipe (red) 6 On/Off button 7 Coolant supply pipe (blue)
8 Compressed air connector
