3-12 Chapter 3
NOTE: The [RAID] option is only available when the item “OnChip Serial ATA” is set as [Enhanced
Mode].
SATA RAID ROM:
This item allows you to use the boot ROM of on-chip Serial ATA RAID to boot-up system.
OnChip Serial ATA:
This item determines the function for on-chip Serial ATA.
[Disabled]: Disable the Serial ATA controller.
[Auto]: Allows the Serial ATA controller to be arranged by BIOS automatically.
[Combined Mode]: Parallel ATA and Serial ATA are combined together. Supports up to 4 IDE drives.
[Enhanced Mode]: Enable both Parallel ATA and Serial ATA. Supports up to 6 IDE drives.
[SATA Only]: The SATA is operating in legacy mode.
AI7/AI7-G
