2-4 Chapter 2
J6 - Hardware Suspend switch
There is no specific orientation. Connect the two-thread hardware suspend
plug to the J6 connector pins on the mainboard. Since most cases do not
support this feature, most of you ignore this instruction. Furthermore, this
feature is not necessary as it is already a part of the mainboard.
Pin number Name or significance of the signal
7 Suspend
6 Ground
J6 - Hardware Reset connector
There is no specific orientation. Connect the two-thread hardware reset cable
to the J6 connector pins on the mainboard.
Pin number Name or significance of signal
1 Ground
2 Hardware reset signal
The “Hardware Reset” is used to reset the computer during
operation without turning the computer off and back on. For
example, if you are running an application that stops
responding to the computer, you may press the Reset button to
restart the computer.
J6 - Speaker connector
There is no specific orientation. Connect the four-thread speaker cable to the
J6 connector pins on the mainboard.
Pin number Name or significance of signal
11 +5VDC
12 Ground
13 Ground
14 Sound Signal
