Introduction of BIOS 3-3
¬
CPU setup
¡i
CPU SOFT MENU™
¡j
The CPU can be setup through a programmable switch (CPU SOFT
MENU™ ), that replaces traditional manual hardware configuration. This feature
allows the user to complete more easily the installation procedures. You can
install the CPU without configuring any jumpers or switches. The CPU must be
setup according its specifications.
In the first option, you can press <F1> at any time to display all the items
that can be chosen for that option.
ROM PCI/ISA BIOS (XXXXXXXX)
!! CPU SOFT MENU!!
AWARD SOFTWARE, INC.
CPU Name Is : Intel Pentium MMX
CPU Type (Speed) : 133 (66x2)
-Turbo Frequency : Disable
-External Clock : 66MHz
-Multiplier Factor : 2
CPU Power Plane : Dual Voltage
-Core Plane Voltage : 2.80v
-I/O Plane Voltage : 3.30v
Esc : Quit
¡ô¡õ¡÷¡ö : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
Fig 3-1 CPU SOFT MENU™
CPU Name Is:
ä Intel Pentium ä Intel Pentium MMX
ä AMD K5 ä AMD K6
ä Cyrix 6x86 ä Cyrix 6x86L
ä Cyrix M2
But when you boot the computer, the mainboard will automatically detect
the CPU brand and type.
