Quick Installation
A-1
Appendix A Quick Installation
Appendix A will give you a simplified installation procedure, in order to
allow you to install tour mainboard quickly and correctly.
If you need further information or if you need to change some other settings,
read from Chapters 1.
Lift up the lever of the CPU socket, insert your
CPU on the socket, and lower the lever back in position. Don’t worry, if you
don’t respect the correct orientation, you will not be able to insert the CPU.
According to your CPU voltage
and speed, set up the CPU in the CPU SOFT MENU™ of the BIOS SETUP.
For information about your CPU, refer to appendices B, C or D, and to
information labeled on the CPU itself.
SIMM1~SIMM4,DIMM1~DIMM2- Since
Pentium are 64-bit CPUs, you have to use two 72-pin DRAM modules, or one
168-pin DRAM module. Refer to the scenarios listed below to install your
DRAM modules.
Scenario 1: Two identical 72-pin DRAM modules:
Insert your DRAM modules into SIMM1 and SIMM2
memory banks.
Scenario 2: Four identical 72-pin DRAM modules:
Insert your DRAM modules into SIMM1, SIMM2, SIMM3
and SIMM4 memory banks.
Scenario 3: Four DRAM modules, identical by pairs:
Insert two identical DRAM modules into SIMM1 and
SIMM2, and the other two identical DRAM modules into
SIMM3 and SIMM4.
Installing the CPU:
Adjusting CPU voltage and speed:
Installing DRAM:
