Installing the Mainboard 2-7
J1 - PS/2 Mouse connector Watch the pin number and the orientation
This has a specific orientation. Connect the six-threads PS/2 Mouse cable
provided to the J1 connector on the mainboard.
Pin number Name of the signal or signification
1 Mouse data
2 No connection
3 Ground
4 +5VDC
5 Ground
6 Mouse clock
The “PS/2 Mouse Port” is different from COM1 or COM2 serial
ports to which you can also connect a Mouse. This mainboard
features an extra PS/2 Mouse port, so when you buy a mouse, be
sure that it is a PS/2 Mouse before connecting it to this port. But
if you cannot find any PS/2 Mouse, you can still use COM1 or
COM2 to connect a serial mouse to your computer.
J2 - PS/2 Keyboard Connector
This has an orientation pin. Connect your keyboard connector to the J2
connector on the mainboard.
Pin number Name of the signal or signification
1 Keyboard data
2 No connection
3 Ground
4 +5VDC
5 Ground
6 Keyboard clock
