Installing the Mainboard 2-17
l
DIMM1 is the first pair, DIMM2 is the second pair. Usually,
you first insert modules in DIMM1 socket, than in DIMM2
socket, but it is possible to do the reverse.
l You can also directly refer to table 2-2.
Scenario 3: You use 72-pin SIMM modules and 168-pin DIMM modules:
l The maximum memory size is: 128M Bytes.
l
Support possible for single density or double density memory
modules.
l Memory modules supported: Refer to case 1 and case 2 above.
l Support possible for mixed use of single density and double
density modules.
l Since there is a lot of possible configurations, no table is given.
