Abit IP35 - Advanced Chipset Features

2-18 IP35/IP35-E
2.8 PC Health Status
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
►
ABIT FanEQ Control Press Enter Item Help
FAN Fail Alarm Selectable CPU FAN
Shutdown When FAN Fail Disabled
CPU Shutdown Temperature 90
°
C/194
°
F
CPU Warning Temperature 80
°
C/176
°
F
CPU Temperature 40
°
C/118
°
F
SYS Temperature 31
°
C/ 88
°
F
PWM Temperature 35
°
C/ 95
°
F
CPU FAN Speed 3245 RPM
SYS FAN Speed 4218 RPM
AUX1 FAN Speed 0 RPM
AUX2 FAN Speed 0 RPM
CPU Core Voltage 1.30V
DDR2 Voltage 1.80V
CPU VTT Voltage 1.20V
MCH 1.25V Voltage 1.25V
ATX +12V 12.00V
ATX +3.3V 3.30V

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
 ABIT FanEQ Control
This item determines the temperature threshold to raise the fan attached at CPU and SYS fan
headers up to their full speed.
Click <Enter> key to enter its submenu:
Phoenix – AwardBIOS CMOS Setup Utility
ABIT FanEQ Control
CPU FanEQ ontrol Enabled Item Help
- CPU FAN Type 4 Pin
- FanEQ Target Temp. 50
°
C/122
°
F
- FanEQ Temp. Tolerance 5
°
C/ 41
°
F
- FanEQ Start Control 80%
- FanEQ Stop Control 50%
SYS FanEQ ontrol Disabled
x
- FanEQ Reference Temp. System
x
- FanEQ Target Temp. 35
°
C/ 95
°
F
x
- FanEQ Temp. Tolerance 5
°
C/ 41
°
F
x
- FanEQ Start Control 70%
x
- FanEQ Stop Control 50%

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
CPU FanEQ Control
When set to [Enabled], these items control the CPU fan speed by the following setting
combinations.
- CPU FAN Type
This item selects your CPU fan type.
