Before the charging procedure
During the charging procedure
After the charging procedure
1 Gently lift the Type 2 charging
connector from its storage
compartment
2 Pull the Type 2 charging connec-
tor down to remove it from the
Type 2 storage compartment
TYPE 2 CHARGING CABLE
3 p. 29
4 p. 29
Type 2 storage
compartment
13. CHARGING
