A27 V3 Series Product User Manual
4.2 Wall mounting
Step 1: Use M6 self tapping screws or M6 expansion screws to fix the frame on
a flat wall. Single or double frames are optional.
Step 2: Install the hanging nails on the installation holes on the back of the
panel, and each frame needs to install 4 hanging nails.
Step 3: Install the panel frame (excluding the module) on the frame: layer by
layer from bottom to top, and complete the installation of the inner connecting
plate.
