Abus CFA3010 - 4.4 Preparing the Door Cylinder

35
3.
1.
2.
1.
2.
3.
X
X < 7 mm
X = 7-12
mm
X
4.2
Replace the cylinder if the mini-
mum projection (7-12 mm) cannot
be achieved or no emergency
feature is included
