22
3.5 Ceiling mount
1. The mounting on the ceiling takes
place via an adapter plate, which is
included in the delivery of the camera.
2. Install the adapter plate at the desired
location on the ceiling first.
3. Cable routing can be in the ceiling or
sideways. For the hidden cable routing
in the ceiling is on the adapter plate a
recess.
4. For a lateral cable routing, please
remove the rubber plug at the point
where the cable is led into the dome.
5. The camera is attached to the adapter
plate by attaching and turning
clockwise.
