3.7 Audio input & Audio output
Description Conneciton notes
A
udio input „
A
UDIO_IN“ MIC / LINE Interface
LINE: 2-2.4Vss, 1KΩ
„AUDIO_GND“
(Ground)
A
udio output „
A
UDIO_OUT“ Impedance: 600 Ω
Frequency range: 20 Hz – 20 kHz
Output power: 20 mW @ 16Ω
„AUDIO_GND“
(Ground)
