23
3.6 Wall mount using wall bracket
1. An optional wall bracket is available
for wall mounting.
2. First attach the adapter platters of the
camera to the wall mount.
3. Loosen the fixing screw on the
underside of the wall bracket. Then
the installation base can be removed
from the back of the wall bracket.
4. Now attach the installation base to
the wall. The cable routing can be
hidden in the wall, up or down.
5. The cables are routed through the
holder.
6. The camera is attached to the
adapter plate by attaching and
turning clockwise.
