5. Description of device
5.1 Overview – item numbers
Item number TVCC40531
Resolution 520 TVL
Lens 5-15 mm
IR
IR cut filter (ICR)
Voltage 12VDC
5.2 Unpacking
While you are unpacking the device please handle it with utmost care.
If you notice any damage of the original packaging, please check at first the device.
If the device shows damages, please contact your local dealer.
5.3 Description of camera
(1) Camera body with sunshield
(2) Joint between camera and camera
bracket (Easy-Plug)
(3) Camera bracket
(4) Connection cable
(5) Connector for video signal
(6) Connector for power supply
(7) Zoom +
(8) Zoom -
1
2
3
4
5
6
8
7
