9. Technical data
Article number TVCC40531
TV Standard
PAL
Resolution
520 TVL
Image sensor
1/3‘‘ Sony Super HAD CCD
Picture elements (total)
795(H) x 596(V)
Picture elements (effective)
752(H) x 582(V)
Signal-to-noise ratio
48 dB
Minimum illumination (day)
0.5 Lux @ F2.2, 30 IRE
Minimum illumination (night)
0 Lux @ F2.2, 30 IRE (IR On)
Day/night
Infrared cut filter (ICR), Color / B/W
IR LEDs
21 LEDs [Ø 5 mm]
Lens (focal length)
f=5-15 mm, F2.2, 5 Levels (5,0 / 7,5 / 10,0 / 12,5 / 15,0 mm)
Horizontal angle of view
41°~19°
Synchronisation
Internal
Automatic gain control
(AGC)
AGC, Auto
Backlight compensation
(BLC)
automatic
White balance
AWB
Protection class
IP66
Video signal
FBAS; 1.0V p-p, 75 Ohm
Operating temperature
-10°C ~ +50°C
Humidity
0~85%, Not condensing
Nominal supply voltage
12 VDC
Current consumption (IR off)
260 mA
Current consumption (IR on)
425 mA
Dimensions (WxHxD)
67.7 x 64.6 x 181 mm
Weight
400 g
67.7mm
12
mm
97mm
183.6mm
66mm
26.2mm
