Abus TVCC80000 - Description of the Connections

28
English
3. Description of the connections
TVCC80000 / TVCC81000:
Outer connections
Inner connections
1
2
3
4
1. Address DIP switch 2. Protocol DIP switch
3. Plug connection 4. Address and protocol settings
1. Alarm In/Out connections (7 IN / 2 OUT)
2. Video output and RS-485 connection
3. 24 V AC power supply / ground connection
3
2
1
