System operation
General information
The device can be controlled as follows:
 Using the USB mouse
Connections on the rear of the device
Note
Pay attention to the overview on page 61.
Name
Function
VIDEO IN:
 BNC input for analogue cameras
AUDIO IN:
 Cinch inputs
AUDIO OUT:
 Cinch audio output (synchronised with the
video output)
VGA:
 VGA monitor connection (9-pin), video output
signal
ALARM IN/OUT:
 Max. 4 alarm inputs, max. 1 relay outputs
POWER ON/OFF:
 On and off device switch
POWER SUPPLY
 12 V DC connection for power supply
RS-485
 Connection for PTZ cameras
LAN
 RJ45 port for a network connection
USB
 Connection for USB devices
HDMI
 HDMI monitor connection
USB
 Connection for USB devices
SHUTTLE KNOB
 For selecting the operating mode
