16. Technical data
Model number
TVIP41660
Dimensions (D x H)
120 x 84 mm
Alarm input (NO/NC)
1.
Danger detection
Email, recording on SD card
Connections
1 x RJ45, 1 x audio input, 1 x audio output, 1 x DC
1 x alarm input, 1 x alarm output
Number of parallel streams
2
Audio output
2-wire
Audio compression: G.711/G.726/MP2L2/G.722
Resolution modes
Main Stream: 1280 x 960, 704 x 576, 640 x 480
Sub Stream: 704 x 576, 640 x 480, 352 x 288, 320 x 240
Motion detection
Yes
Image sensor
1/3 inch progressive scan CMOS
Pixels (effective)
1280 x 960 pixels
Image overlay
Date, camera name, private zones
Frame rate
25 fps
Focal length
4.0 mm @ F2.0
Camera type
Day/night
Dynamic range (WDR)
Digital WDR
Electronic shutter regulation
1/3 1/100000 Sec.
Backlight compensation
BLC, DWDR
Simultaneous network
access
Yes
Horizontal angle of view
33-80°
Camera type
Day/night pan/tilt/zoom camera
Max. resolution @ frame
rate
1280 x 960 @ 25 fps
Max. operating temperature
50°C
Max. humidity
90%
Microphone
Yes
Min. operating temperature
-10°C
Minimum illumination colour
0.1 Lux @(F1.2, AGC an)
Minimum illumination B/W
0 Lux
Video network bandwidth
32 kBit/s 8 MBit/s
LAN network access
RJ-45 Ethernet 10/100 Base-T
WLAN network access
IEEE802.11b, 802.11g, 802.11n
Network camera protocols
Bonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, NTP,
UPnP, RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA RTSP
ONVIF
Profile S
Private zones
Yes (8)
Noise reduction
DNR
IP protection class
54
Pan/tilt area
355°/-20° 90°
Power supply
12 V DC (+/-10 %)
Storage medium
microSD card (up to 64 GB)
Language of instructions
DE, UK, FR, NL, DK, ES, IT, PL, RU, SWE
OSD language
DE, UK, FR, NL, DK, ES, IT, PL, RU, SWE
Current consumption
Max. 500 mA
Day/night switching
Electromechanically removable IR cut filter (ICR)
Supported browsers
Mozilla Firefox, Safari or Internet Explorer 6.x and higher
Supported software
ABUS VMS Express, IPCam App (iOS/Android)
Encryption
64/128 bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Video compression
H.264, MJPEG
White balance
AWB
Certifications
CE, RoHS, REACH
147
