AC Infinity ADVANCE GROW - CLOUDLINE LITE Fan Installation; Disassembling Fan for Mounting

28
CLOUDLINE LITE
INSTALLATION: MOUNTING
STEP 2
Remove the motor box from the flange
bracket. Remove the wind circle between
the motor box and the intake flange.
STEP 1
Unscrew the bolts on both sides from the
plastic rings using a Philips screwdriver.
