26
CONTROLLER MOUNTING
MAGNET MOUNTING
Mount the controller on a steel surface using
the magnet located behind the label.
PLATE MOUNTING*
Screw the controller plate bolts into the slot or
mounting holes at the upper half of the plate.
Hang the controller by the bolts using the hole
on the backside.
S-SERIES
*Controller plate not included
