20
T-SERIES CONTROLLER
Smart controllers for T-Series models with DC motors can support two fans of the same tier model.
For example, the CLOUDLINE T4 can only support an S4 fan, the CLOUDLINE T6 can only
support an S6 fan and so on.
Smart controllers for T-Series models with EC motors can support two fans of any size. The two
EC-motor fans must be plugged in to an outlet to power the fans and the controller. See images
below.
ADDING MORE FANS
The smart controller for the CLOUDLINE T-Series
has an additional port so that you can add an
S-Series fan to power and control two fans together.
Please see below for limitations.
EC MOTORDC MOTOR
T6//S6
T4//S4T4//S4 T4//S4
