Installation
3.2.2 Fuses/cable cross-sections
Note
Observe local regulations.
Local codes may supersede these recommendations
Type
Recommendations
Fuse
Miniature
circuit
breaker
(1)
Fuse
(2)
or
Breaker
(3)
(N. America)
Input Power Wiring
(L1, L2, L3, PE)
[mm²] [AWG]
120V
1~
(1/N/PE)
M10 A C10 A 10 A 1.5 14
M16 A C16 A 15 A 2.5 1
4
M25 A C25 A 25 A 4 1
0
240V
1
~
(2/PE)
M10 A C10 A 10 A 1.5 14
M16 A C16 A 15 A 2.5 1
4
M20 A C20 A 20 A 2.5 1
2
M25 A C25 A 25 A 2.5 1
2
M32 A C32A 32 A 4 1
0
240V
3
~
(3/PE)
M10 A C10 A 10 A 1.5 14
M12 A C12 A 12 A 1.5 14
M20 A C20 A 20 A 2.5 1
2
M32 A C32 A 32 A 4.0 1
0
M35 A C35 A 35 A 6.0 8
M45 A C45 A 45 A 1
0 8
400V
or 480V
3~(3/PE)
M10 A C10 A 10 A 1.5 14
M16 A C16 A 20 A 2.5 1
4
M20 A C20 A 20 A 2.5 1
4
M25 A C25 A 25 A 4.0 1
0
600V
3~(3/PE)
M10 A C10 A 10 A 1.5 14
M12 A C12 A 12 A 1.5 14
M16 A C16 A 15 A 2.5 1
4
M20 A C20 A 20 A 2.5 1
2
(1) Installations with high fault current due to large supply mains may require a type D circuit breaker.
(2) UL Class CC or T fast-acting current-limiting type fuses, 200,000 AIC, preferred. Bussman KTK-R, JJN or JJS or equivalent.
(3) Thermomagnetic type breakers preferred.
Observe the following when using Ground Fault Circuit Interrupters (GFCIs):
• Installation of GFCI only between supplying mains and controller.
• The GFCI can be activated by:
- capacitive leakage currents between the cable screens during operation (especially with long,
screened motor cables)
- connecting several controllers to the mains at the same time
- RFI filters
To Next Page
