ENGLISH
29
Commissioning
4.5.6 Network Parameters
Code Possible Settings
IMPORTANT
No. Name Default Selection
Network Protocol 0 Not Active
This parameter will only display
the selection for the module that is
installed.
1 Remote Keypad
2 Modbus RTU
3 CANopen
4
DeviceNet
5 Ethernet
6 Profibus
…
Module Specific Parameters
Refer to the Reference Guide specific
to the module installed.
4.5.7 Diagnostic Parameters
Code
Display Range
(READ ONLY)
IMPORTANT
No. Name
Fault History • Displays the last 8 faults
• Format: n.xxx
where: n = 1
..8;
1 is the newest fault
xxx = fault message (without the
.)
• see Section 5.3
Software version Format: x.yz
Drive ID A flashing display indicates that the Drive ID
stored in the EPM does not match the drive
model it is plugged into.
Internal Code Alternating Display: xxx-; -yy
DC Bus Voltage 0 {VDC} 1500
Motor Voltage 0 {VAC} 1000
Load 0 {%} 255 Motor load as % of drive’s output current rating.
See section 2.2.
Motor Current 0.0 {A} 1000 Actual motor current
Torque 0 {%} 500 Torque as % of motor rated torque
(vector mode only)
kW 0.00 {kW} 650.0
kWh 0.0 {kWh} 9999999 Alternating display: xxx-; yyyy when value
exceeds 9999
Heatsink Temp 0 {°C} 150 Heatsink temperature
0-10 VDC Input 0.0 {VDC} 10.0 Actual value of signal at TB-5
4-20 mA Input 0.0 {mA} 20.0 Actual value of signal at TB-25
TB-5 Feedback P204 P205 TB-5 signal value scaled to PID feedback units
TB-25 Feedback P204 P205 TB-25 signal value scaled to PID feedback units
