Troubleshooting and Diagnostics
Status / Warning Cause Remedy
PID Mode Active Drive has been put into PID
Mode. See P200.
Sleep Mode is active See P240...P242
Start Pending The drive has tripped into a fault
and will automatically restart
(P110 = 3...6)
To disable Auto-Restart, set
P110 = 0...2
PID Mode disabled. Drive has been taken out of PID
Mode. See P200.
Output frequency = 0 Hz
(outputs U, V, W inhibited)
Stop has been commanded from
the keypad, terminal strip, or
network
Apply Start command (Start
Control source depends on
P100)
5.2 Drive Conguration Messages
When the Mode button is pressed and held, the drive’s display will provide a 4-digit code that indicates
how the drive is configured. If the drive is in a Stop state when this is done, the display will also
indicate which control source commanded the drive to Stop
(the two displays will alternate every second).
Conguration Display
Format = x.y.zz x = Control Source:
= Local Keypad
= Terminal Strip
= Remote Keypad
= Network
y = Mode:
= Speed mode
= PID mode
= Vector Torque mode
zz = Reference:
= Keypad s t
= 0-10 VDC (TB-5)
= 4-20 mA (TB-25)
= Jog
= Network
= MOP
= Preset 1...7
Example:
•
= Local Keypad Start control, Speed mode, Keypad speed reference
•
= Terminal Strip Start control, PID mode, 0-10 VDC setpoint reference
•
= Network Start control, Vector Torque mode, Preset Torque #2 reference
Stop Source Display
Format = x
= Stop command came from Local Keypad
= Stop command came from Terminal Strip
= Stop command came from Remote Keypad
= Stop command came from Network
