ENGLISH
21
Commissioning
Code Possible Settings
IMPORTANT
No. Name Default Selection
TB-14 Output 0 0...23 (same as P140)
24 Dynamic Braking For use with Dynamic Braking option
25 Network Activated Requires optional communication
module (refer to the network module
documentation).
Loss of Load
Threshold
0 0 {%} 200 P140, P142 = 10: Output will energize
if motor load falls below P145 value
longer than P146 time
Loss of Load
Delay
0.0 0.0 {s} 240.0
TB-30 Output 0 0 None 2-10 VDC signal can be converted to
4-20 mA with a total circuit impedance
of 500 W
1 0-10 VDC Output Frequency
2 2-10 VDC Output Frequency
3 0-10 VDC Load
4 2-10 VDC Load
5 0-10 VDC Torque
6 2-10 VDC Torque
7 0-10 VDC Power (kW)
8 2-10 VDC Power (kW)
9 Network Controlled
Requires optional communication
module (refer to the network module
documentation).
TB-30 Scaling:
Frequency
60.0 3.0 {Hz} 2000 If P150 = 1 or 2, sets the frequency at
which output equals 10 VDC
TB-30 Scaling:
Load
200 10 {%} 500 If P150 = 3 or 4, sets the Load (as a
percent of drive current rating) at which
output equals 1
0 VDC.
TB-30 Scaling:
Torque
100 10 {%} 1000 If P150 = 5 or 6, sets the Torque (as a
percent of motor rated torque) at which
output equals 10 VDC
TB-30 Scaling:
Power (kW)
1.0 0.1 {kW} 200.0 If P150 = 7 or 8, sets the power at
which output equals 10 VDC
