Panel Disassembly Method
1.
Upper panel: Open the front door and lift the upper panel, then the back magnets will be separated and
disassembled.
2.
Front panel: Remove the lower set screws of the drain box, then loosen the set screws on the top of
the front panel and pull out the front panel taking both sides.
3.
Side panel: Open the door, loosen the screws on the top of the front panel, push the front panel
forward, and slide the side panel forward to remove it.
•
Precede the assembly work in the reverse order of disassembly.
Side Panel
