AccuEnergy Acuvim II AXM-IO1 User Manual

10
IO Modual
DI Sequence: AXM-IO11 (AXM-IO1 module in sub address 0):DI1-6
AXM-IO21 (AXM-IO2 module in sub address 0):DI7-10
AXM-IO31 (AXM-IO3 module in sub address 0):DI11-14
AXM-IO12 (AXM-IO1 module in sub address 1):DI15-20
AXM-IO22 (AXM-IO2 module in sub address 1):DI21-24
AXM-IO32 (AXM-IO3 module in sub address 1):DI25-28
RO Sequence: AXM-IO11 (AXM-IO1 module in sub address 0):RO1-2
AXM-IO31 (AXM-IO3 module in sub address 0):RO3-4
AXM-IO12 (AXM-IO1 module in sub address 1):RO5-6
AXM-IO32 (AXM-IO3 module in sub address 1):RO7-8
DO Sequence: AXM-IO21 (AXM-IO2 module in sub address 0):DO1-2
AXM-IO22 (AXM-IO2 module in sub address 1):DO3-4
AO Sequence: AXM-IO21 (AXM-IO2 module in sub address 0):AO1-2
AXM-IO22 (AXM-IO2 module in sub address 1):AO3-4
AI Sequence: AXM-IO31 (AXM-IO3 module in sub address 0):AI1-2
AXM-IO32 (AXM-IO3 module in sub address 1):AI3-4
Wiring of Digital Input Circuit:
There are 6 digital input circuits, 4 digital input circuits and 4 digital
input circuits in AXM-IO1, AXM-IO2 and AXM-IO3 modules respectively. The
digital input circuit can be used to detect remote signals, or be used as a
counter of input pulses.
