IO Modual
Appendix A Technical Data and Specication
of IO Modules
Digital inputs (DI)
Input Type Wet contact (Contact with power supply)
Input Voltage Range 20
～
250Vac/dc
Input Current Draw (Maximum) 2mA
Turn on Voltage 20V
Turn off Voltage 5V
Maximum Input frequency for
counter
100Hz with 50
％
duty cycle
（
5ms ON, 5ms OFF
）
SOE resolution 2 ms
Isolation Voltage 2500V
Digital Output AC DC Rating (Photo-MOS)
Output Form Form 1A
Load Voltage Range 0-250Vac/dc
Load Current 100mA (Maximum.)
Maximum output frequency 25Hz with 50
％
duty cycle (20ms ON, 20ms OFF)
Isolation Voltage 2500V
Relay Output Rating (RO)
Output Form Form 1A
Load voltage Range 250Vac, 30Vdc
Load Current 3A
Turn on Time 10ms (Maximum)
On-state Impedance 100mΩ (Maximum)
Isolation Voltage 2500V
Expected Mechanical Life 15 million
